Name: 125mm Dia., 3mm Thick, Uncoated, λ/4 Fused Silica Window
Brand: TECHSPEC
SKU: 20-161
Price: RMB 4,539.21

125mm Dia., 3mm Thick, Uncoated, λ/4 Fused Silica Window

TECHSPEC® λ/4 UV Fused Silica Windows

产品编码 #20-161 6-10 工作日

- +

RMB 4,539.21

数量 1-5
RMB 4,539.21

数量 6+
RMB 3,631.37

含税批量价格
索取报价

+ 添加至收藏夹
Create an account or log in to access saved list

产品对比

下载产品资料

色散系数 (v_d):

67.8

倒角:

Protective as needed

有效孔径 (%):

有效孔径 CA（mm）:

112.50

直径 (mm):

125.00 +0.00/-0.20

厚度 (mm):

3.00 ±0.10

涂层:

Uncoated

热膨胀系数 CTE (10^-6/°C):

0.52 (+5 to +35°C)
0.57 (0 to +200°C)
0.48 (-100 to +200°C)

密度 (g/cm³):

2.20

边缘:

Fine Ground

折射率 n_d:

1.458

努氏硬度 (kg/mm²) :

522

平行度（弧分）:

泊松比 :

0.16

基底: Many glass manufacturers offer the same material characteristics under different trade names. Learn More

Fused Silica (Corning 7980)

表面质量:

40-20

传输波前，P-V (λ):

λ/4 (per inch within clear aperture)

类型:

Protective Window

波长范围 (nm):

200 - 2200

杨氏模量 (GPa) :

合规性

RoHS:

符合标准

Certificate of Conformance:

浏览

产品系列说明

提供适用于 UV、可见光和 NIR 的无镀膜选件或有 BBAR 镀膜的选件
非常适用于成像应用
标准直径从 10 至 75mm
还提供1λ 或 λ/10 UV 熔融石英窗口片

TECHSPEC® λ/4 UV 熔融石英窗口片经过精心制造，其规格具有 40-20 的表面质量和 λ/4 的传输波前误差，因此非常适用于成像应用。这些窗口片采用 UV 熔融石英基片，在从紫外 (UV) 到可见光和近红外 (NIR) 的范围内能提供很高的透射率。有宽带增透 (BBAR) 膜的选件可最大限度减少反射损失，并提高透射率。TECHSPEC λ/4 UV 熔融石英窗口片用于光学成像应用和低功率至中功率的激光应用中，还可以用作保护性窗口片，尤其是在需要透射紫外线的应用中，更是如此。

技术信息

FUSED SILICA
	Typical transmission of a 3mm thick, uncoated fused silica window across the UV - NIR spectra. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with MgF2 (400-700nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_avg ≤ 1.75% @ 400 - 700nm (N-BK7) Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with UV-AR (250-425nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_abs ≤ 1.0% @ 250 - 425nm R_avg ≤ 0.75% @ 250 - 425nm R_avg ≤ 0.5% @ 370 - 420nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with UV-VIS (250-700nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_abs ≤ 1.0% @ 350 - 450nm R_avg ≤ 1.5% @ 250 - 700nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with VIS-EXT (350-700nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_avg≤ 0.5% @ 350 - 700nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with VIS-NIR (400-1000nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_abs≤ 0.25% @ 880nm R_avg≤ 1.25% @ 400 - 870nm R_avg≤ 1.25% @ 890 - 1000nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with VIS 0° (425-675nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_avg≤ 0.4% @ 425 - 675nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with YAG-BBAR (500-1100nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_abs ≤ 0.25% @ 532nm R_abs ≤ 0.25% @ 1064nm R_avg≤ 1.0% @ 500 - 1100nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with NIR I (600 - 1050nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_avg≤ 0.5% @ 600 - 1050nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
	Typical transmission of a 3mm thick fused silica window with NIR II (750 - 1550nm) coating at 0° AOI. The blue shaded region indicates the coating design wavelengh range, with the following specification: R_abs ≤ 1.5% @ 750 - 800nm R_abs ≤ 1.0% @ 800 - 1550nm R_avg≤ 0.7% @ 750 - 1550nm Data outside this range is not guaranteed and is for reference only. Click Here to Download Data
