Laser Microscopy

Laser Optics

Laser Microscopy is used to image samples through the use of focused laser beams. In general Laser Microscopy applications, a sample is scanned by a focused laser beam and the intensity of the reflected beam is converted to a digital image. Confocal microscopy, also known as confocal laser scanning microscopy, offers various advantages over traditional wide-field microscopy, such as enhanced resolution, targeted imaging location, and higher image depth. Common laser microscopy techniques include super-resolution microscopy, fluorescence microscopy, and two- or multi-photon microscopy.

Edmund Optics offers a range of Laser Microscopy objectives in finite and infinite conjugate styles for use with common laser wavelengths, such as those of popular laser diodes or Nd:YAG harmonics. Our TECHSPEC® ReflX™ Objectives are reflective microscope objectives that can efficiently focus laser light without introducing any chromatic aberration. These objectives feature a rugged design to withstand exposure to moderate heat or abrasion and are ideal in applications that range from FTIR spectroscopy to semiconductor inspection. TECHSPEC® High Performance ReflX™ Objectives are also available, providing better peak-to-valley transmitted wavefront and a design that allows for angles of incidence up to 45°. Mitutoyo Objectives, with excellent performance at Nd:YAG harmonics, are ideal for integration into semiconductor inspection or laser cutting applications.

ReflX™ 反射物镜
TECHSPEC® 组件由爱特蒙特光学设计、规定或生产。 了解更多

ReflX™ 反射物镜
  • 具有行业领先水平的 19 至 31mm 工作距离
  • 爱特蒙特光学公司为聚焦或成像应用而设计并制造
  • 主动对准,以获得最佳性能
  • 从190nm 至 11μm 的超宽光谱带且无色差
高品质ReflX™反射物镜
TECHSPEC® 组件由爱特蒙特光学设计、规定或生产。 了解更多

高品质ReflX™反射物镜
  • 衍射极限性能:传输波前,RMS: λ/14
  • 锥形设计可以在45度入射角的时候方便的安装和拆卸
  • 为降低衍射效应采取了弯曲结构
  • 具有行业领先水平的 24 至 31mm 工作距离
Mitutoyo NIR,NUV,和UV 远场校正物镜
Mitutoyo NIR,NUV,和UV 远场校正物镜
  • 全新设计的M Plan NIR HR 和 M Plan UV镜头
  • M Plan NIR HR 镜头提高了分辨率
  • M Plan UV 镜头 在266nm 和550nm 进行优化
Mitutoyo 远场校正长工作距离物镜
Mitutoyo 远场校正长工作距离物镜
  • 工作距离长,100倍时6mm
  • 复消色差光学设计
  • 整个像场平场结构
用于红外波段的硒化锌聚焦镜
用于红外波段的硒化锌聚焦镜
  • 最大程度将光束耦合效率提高到5mm
  • 可方便地与HeNe 激光器准直
  • 使用波段为 2 - 12μm
可调ReflX™ 物镜
TECHSPEC® 组件由爱特蒙特光学设计、规定或生产。 了解更多
Clearance
×

可调ReflX™ 物镜
  • 反射物镜可调节,适用于精密校准
  • 可选多种镀膜,适用于特定波长范围
  • 采用有限共轭设计和RMS螺纹,可轻松集成在多种物镜设置中

×
